Product parameters
SPECIFICATIONS
ELECTRICAL:
UL APPLICATIONS: 250 VOLTS AC MAX., AT 2 AMPS.
DIELECTRIC WITHSTANDING VOLTAGE: 500 VOLTS AC,
INSULATION RESISTANCE: 100M Ω
TERMINATION: RESISTANCE 20mΩ MAX AFTER
ENVIRONMENTAL TESTING.
2.MECHANICAL:
CABLE-TO-PLUG TENSILE STRENGTH: 20kg MIN,
DURABILITY : 200 MATING CYCLES
3.MATERIAL & FINISH:
HOUSING: POLYCARBONATE
COLOR : TRANSPARENT
CONTACT BLADE: PHOSPHOR BRONZE.
CONDUCTOR : STRANDED & SOLID WIRE , 24AWG, 26 AWG
GOLD PLATING: 3u -50u"ARE AVAIlABLE.
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SLU6APG88M03 | Cat.6A UTP 8P8C Plug | 10000 PCS | 40*29*53 | 15 KG |
